EasyCheck Dual Magnification Fiber Endface Inspector
One focus, double rate effective detection
Clear image quality
A comprehensive interface group
Automatically scan and store images (EC400/200)
Optional foot switch switching ratio (EC400/200)
Product Overview
The double rate fiber end face detector of Dimension Technology achieves fast and effective detection of fiber end face quality at double rate through dual screen display or switching display It can detect fine defects at high rate and acute large area detection at low rate The advantage of this device is that one workstation, one device, and one focus can achieve double rate fiber end face detection, saving detection workstations, improving detection efficiency, and reducing production costs
Main features
One focus, double rate effective detection
Clear image quality
A comprehensive interface group
Automatically scan and store images (EC400/200)
Optional foot switch switching ratio (EC400/200)
Main applications
EC200/80KML is mainly used in fiber optical connectors and optical receivers; Module, TOSA/ROSA; Equal end face inspection
EC400/200 is mainly used for variable fiber optical connectors; End face inspection
EC200/40KC is mainly used for end face inspection of various products such as fiber optic connectors, TOSA/ROSA components, etc;
Double rate effective detection
With one focus, EC200/80KML can simultaneously view the condition of the 200X and 80X double magic lower end faces through dual screens, and can also switch magic through buttons; EC400/200 switches between 400X and 200X magnetization through buttons or foot switches (optional) Detecting fine defects at high magnetization and detecting large areas at low magnetization can save inspection workstations, improve inspection efficiency, and reduce production costs
Clear image quality
The EasyCheck double rate fiber optical end face detector utilizes the optimal optical system design, high resolution image sensors, and an 8 "pure black and white digital TFT&Nbsp; The monitor truth displays the detailed appearance of the fiber optical end face for you
A comprehensive interface group
EasyCheck double rate fiber optic end face detector, required with multiple adapters; Mouth, can meet various fiber optical connectors, optical transfer modules, and; TOSA/ROSA and other end face inspection requirements
Conventional auxiliary functions (EC400/200)
To meet the operability of production line employees, EC400/200 has added automatic scanning and image storage functions, as well as foot switch triggered double rate switching functions, making it more convenient and flexible to use
Performance parameter
Type | EC400/200KC 丨 EC400/200KD | EC200/80KML | EC200/40KC |
Magnification | 400X/200X | 200X/80X | 200X/40X |
X Y Adjustment | Adjustable | Adjustable | Adjustable |
Focus | Manual | Manual | Manual |
Image Output | —— | AV OUT | AV OUT |
Display | 8 "TFT 800X600 PIX | 8 "TFT 800X600 PIX | 8 "TFT 1024 * 768 PIX |
Interface | 3 * USB, 1 * SD, 1 * Ethernet | —— | —— |
Power Consumption | 3W | 3W | 3W |
Working Temperature | -10 ℃~40 ℃ | -10 ℃~40 ℃ | -10 ℃~40 ℃ |
Storage Temperature | -20 ℃~55 ℃ | -20 ℃~55 ℃ | -20 ℃~55 ℃ |
Power Supply | DC 12V | DC 12V | DC 12V |
Weight | 1.6kg | 1.6kg | 1.6kg |
Size | 270mmX245mmX155mm | 270mmX245mmX155mm | 270mmX245mmX155mm |
