OT-200 Multi-Fiber MPO Optical Time Domain Reflectometer

Designed for multi-core fiber testing, with a variety of models available to meet diverse testing requirements. Supports FTTx network inspection, troubleshooting, and private network maintenance, helping improve fiber network testing efficiency and operational reliability.

One-touch testing, automatic channel switching, supporting up to 24 fiber cores

Customizable test channels

Platform-based modular design, integrating multiple functions into one device

Intelligent graphical data display

MPO adapter with built-in dust protection

Compact and portable design, lightweight and suitable for one-handed operation

Extended battery life, featuring a unique replaceable smart battery for uninterrupted operation

Selectable single-mode and multi-mode fiber types

Product Details
Specification Parameters
Document Download
Service Support
Related Products
Product Details


Product Overview

As MPO/MTP connectors become increasingly common in high-density cabling environments such as FTTx networks, data centers, and enterprise networks, efficient deployment and maintenance of multi-fiber cables have become important challenges in optical communications.

Dimension Technology's OT-200 Series combines a multi-channel optical switch with optical time domain reflectometry (OTDR) in an integrated testing platform. Specifically designed for high-density multi-fiber deployments, the OT-200 supports comprehensive fault diagnosis for optical links with up to 24 fibers.

Unlike conventional testing methods that require manual switching between individual fiber paths, the OT-200 automatically switches between channels, reducing repetitive operations and improving deployment and maintenance efficiency.

The instrument is suitable for a wide range of optical fiber testing applications, including network installation, troubleshooting, and routine maintenance.



Key Features

  • One-touch testing with automatic channel switching for up to 24 fibers

  • User-defined test channels

  • Modular platform architecture with integrated testing functions

  • Intelligent graphical visualization of measurement data

  • Built-in dust protection for the MPO adapter

  • Compact and portable design for one-handed operation

  • Replaceable smart batteries for extended operating time

  • Selectable single-mode and multimode configurations



Main Applications

• Deployment of high-density fiber optic systems in data centers and other integrated projects

•  MPO fiber cable installation in enterprise networks and central networks

•  Fault diagnosis of multi-core fiber optic links


One-touch testing with automatic channel switching, supporting up to 24 fiber cores

The device supports one-stop fault diagnosis for multi-core fiber optic cables, covering up to 24 fiber cores. It eliminates the need for traditional manual optical path switching and repeated testing of each individual core, significantly improving deployment efficiency while reducing the complexity of maintenance and troubleshooting for technicians.




Customizable Channel Testing

The OT-200 series not only performs basic OTDR link analysis across all MPO channels but also allows users to select specific output channels in multi-core fiber links through optical switch control. The software features a dedicated user interface, with a front-view MPO end-face simulation in the upper-right corner to visualize the current link configuration, helping users improve testing efficiency and streamline operation.

Multifunctional Integration





Intelligent Graphical Data Display

Intuitively visualizes the fiber core status of currently preset tasks and uses color indicators to clearly highlight the actual condition of each fiber link.



Selectable Single-Mode and Multi-Mode Fiber Types

The OT-200 series offers optical switches compatible with both single-mode and multi-mode fibers, meeting testing requirements in different application environments.


Built-in Dust Protection

The OT-200 features adapters with an integrated dust-proof design, effectively preventing contamination or damage to the ports when not in use.




Compact and Portable Design, Rugged Housing, and One-Handed Operation

Thanks to Dimension Technology's excellent ergonomic design and compact, portable form factor, the OTDR series offers multiple carrying options with a modern and stylish appearance. Operation is simple and intuitive: just press the shortcut key to start testing, while test data is automatically analyzed and saved. With minimal training, even beginners can easily perform communication fault inspections.



Versatile Device Integration

This OTDR seamlessly integrates into Dimension Technology's product ecosystem. It can communicate via Wi-Fi or USB and use a dedicated app to control other test devices, functioning as a master device. Alternatively, it can be controlled by other master devices through wired USB or RJ45 connections, serving as an independent test module within a testing system.


Extended Battery Life, Featuring a Unique Replaceable Smart Battery for Uninterrupted Operation

The entire Dimension Technology OTDR series is equipped with replaceable, high-capacity smart batteries. The batteries can be charged independently and replaced whenever needed. Users can also carry spare batteries to ensure continuous operation without power interruptions.



Adaptable to Various Environments and Extreme Weather Conditions

To meet the needs of different application scenarios and field technicians, Dimension Technology has specifically enhanced the reliability of this series of test equipment, making it more versatile, flexible, and suitable for a wide range of operating environments.



Technical Specifications



Performance Specifications



Example:

Model: OT-200-2134-XX-MAF#1310/1550-12

12-fiber OTDR, dual-wavelength, single-mode, 34 dB dynamic range, equipped with an MPO/APC/Female connector, operating at wavelengths of 1310 nm and 1550 nm.
